Stab Vest | Every Question You Need Answer For – In 2024

Ever wondered what military officials, policemen, or other security staff wear over their uniform? It appears like a heavy case-like jacket with several pockets. Well, we’re here to discuss one of the types of those jackets that are called stab vests. However, most of those who know are unclear about whether bulletproof vests and stab vests are the same. In this post, we will try to clear all your doubts regarding stab vests. Besides this, we will discuss everything you should know about the topic. Let us start with a brief introduction to a stab vest

What is a Stab Vest ?

A stab vest is a type of body armor that is reinforced to protect against sharp-tipped objects like blades, knives, spikes, shanks, meat cleavers, and other such objects. These vests are designed for security personnel, policemen, military, paramedics, immigration officers, and bailiffs. Unlike bulletproof jackets, stab vests offer little to no protection against firearms. Stab vests protect from attacks from all sides including the chest, back, and sides as these are the most damage-prone areas to the stabbing. One can wear them over or under clothing and stay protected against attacks from sharp objects.

How is a Stab Vest Made ?

High-performance composites like Carbon fiber, Kevlar, or ultra-high molecular weight polyethylene (UHMWPE) are used to manufacture stab vests.

Kevlar is a strong synthetic fiber that is thermally stable. Besides this, it also has high tensile, high modulus, and low density. Apart from stab vests, Kevlar is also used to make a wide range of high-performance products.

On the other hand, if we talk about UHMWPE, it is an extremely tough abrasion & wear-resistant plastic. This makes it ideal for making stab vests. Besides this, UHMWPE is also used for a variety of other purposes.

These materials are woven into a multi-layered web of fibers to make vests that are stab-resistant vests They are made in different sizes with adjustable straps to ensure a perfect fit.

Carbon fiber kevlar

Is there any type of Stab Vest ?

Stab vests are certified based on the level of protection they offer. As per this, they can be categorized into different types:

SP1- These stab vests offer protection against spikes and shanks.

KR1- These stab vests are to protect against damage from knives and sharp-edged weapons.

VPAM W5- These vests are ideal to safeguard yourself from blunt force trauma like kicks or punches, hypodermic needles, and other impacts from blunt objects.

ISO 20471:2013This ISO certification means that the stab vests are certified for high visibility.

Besides these, vests are also available that offer protection from both sharp objects as well as firearms. For such purposes, KP1/SP1 vests are commonly used.

Along with these types, stab vests are also available in different designs i.e., to be worn over or under clothing, etc.

What are the Different levels of Stab Resistance?

The levels of stab vests are differentiated based on the amount of force a vest can bear that is delivered with each strike. Three NIJ standard protection levels are there for stab vests:

Spike 1 Vest

These vests protect against low energy impacts that deliver a force of around 24 Joules.

Spike 2 Vest

Spike 2 vests can protect against impacts of around 33 Joules.

Spike 3 Vest

The highest level of protection is offered by spike 3 vests and they can protect against impacts of up to 43 Joules.

What does it mean , that the Stab Proof Vest is Certified?

A certified stab-proof vest signifies that it has passed stringent quality checks before being approved fit for use. The testing of stab-resistant vests is done using a special machine that drops a knife on the vest at certain energy/pressure levels. The knife drops multiple times repeatedly to conform to the NIJ standards. The energy at which the knife is dropped depends on the protection level for which the vest needs certification. As for level 1 protection, the knife strikes the vest at 24 joules of pressure, and for the vest to pass the test, the knife should not penetrate the vest more than 7mm. Similarly, at a pressure of 36 joules, the penetration should not be more than 20mm.

To get the certification, the testing is done at a certified laboratory as well as in-house.

Standard for Stab Proof Vest Testing

NIJ 0115.00 is the standard for stab vest testing and anyone who has  the license to manufacture these vests must meet the testing criteria to this NIJ standard. This standard NIJ 0115.00 is the minimum requirement for body armor. It ensures that the stab vest is capable enough to stop the highest-quality knives that one can buy from the shops from penetrating the body of the wearer. This NIJ standard also applies to spike armor.

NIJ 0115.00 Types of Threats

NIJ 0115.00 standard ensures that the stab vest can prevent the wearer from threats like knife attacks, spikes, and other pointed & edged weapons. The standard tests the vests to meet all these criteria before approving goods to go.

NIJ levels of protection

NIJ 0115.00 Levels of Protection

Based on the NIJ 0115.00 standard, there are three levels of protection for stab vests:

Level 1

This is the lowest level that protects the stab-resistant vest wearer against low-energy impacts, especially that strike with the energy of 24 J. These stab vests can be worn under clothing.

Level 2

Level 2 stab-proof vests are best suited for medium energy threats with a strike energy of 33 J.

Level 3

This is the highest level of stabbing vest that protects against high energy impacts with the strike energy of 43 J.

How does a Stab Proof Vest Work?

As we’ve discussed stab vests are made of multiple layers of woven material, especially Kevlar or UHMWPE. So, when someone tries to stab, the fibers of stab vests move around the point of the weapon. This makes the weapon move back & forth after hitting the material. When a sharp object hits the vest, it moves in another direction after hitting some of the fibers of the vest. It reduces the rate at which the weapon pierces the vest and prevents full puncture from occurring.

A stab vest can be used multiple times even if there is a bit of damage as the material does not lose its integrity. However, it is important to keep checking the quality of the vest after multiple uses as the protection level may reduce if there is too much damage.

How Effective are Stab Vests as Protection against Knives

Well, stab vests are designed to offer protection against sharp and pointed objects like knives, spikes, and shanks. However, the effectiveness of vests completely depends on their level. The higher the level more protection the vest will offer. Thus, level 3 stab vests offer the most protection.

KR1 vests are best at protecting against knives. While on the other hand, SP1 vests are certified to protect against shanks and spikes. Above all, you can also avail of SP1/KR1 vests that offer protection against both knives and pointed objects like spikes. These vests (KR1 & SP1) are of level 1 protection and are also available in KR2 and SP2 levels.

What is the testing Standard for a Stab Proof Vest?

The testing standard for stab-proof vests is NIJ standard-0115.00. This is the only standard created for the regulation of stab-resistant armor. It specifies minimum requirements for body armor to protect against sharp objects, edged blades, and pointed weapons.

The goal of this NIJ standard-0115.00 is to establish an international regulation for law enforcement and guide officers for the improvement in overall on-job safety. Armor manufacturers must follow these standards to ensure the quality of the product and the safety of the user.

How Does Stab Vests Are Tested?

The testing of stab vests according to their levels is very important before approving fit for use. While testing, special machines are used to hit the vest with a sharp object at different energy levels of impact. Besides this, the angle of incidence also plays a vital role in ensuring the quality of stab-resistant vests.

The angle of incidence can be defined as the angle at which a sharp object hits the vest. This is also vital in ensuring the quality of the vests. For example, if you are hit with a straight knife, the penetration rate will be higher when compared to being hit with an angled knife. So, during the testing of stab-resistant vests, the NIJ prioritizes the angle of incidence as well along with other factors. So, this is how stab vests are tested before they move to the inventory.

How Do I know if the Armor is Certified By the NIJ?

While buying a stab vest, it is very important to confirm that it is certified by the NIJ. For that, you need to know certain points, and only your stern discretion can protect you. Here are certain signs that could help you know whether the vest is NIJ-certified:

  • There must be the name, logo and certifications along with the unique ID, contact information, and address of the manufacturer on the label of the vest.
  • The upper right corner of the label must have a colored shape corresponding to the protection level that is as follows:
  • Solid blue square of size 1.0 inches – Edged blade protection class
  • A Solid green equilateral triangle of height 1.0 inches – Spike protection class
  • The number of the level of protection i.e., 1 or 2, must be there inside the shape in white color with a height of 1.2 inches.
  • The size, lot number, manufacturing date, lot number, serial number, care instructions, model designation, and warning of non-ballistic resistance must be there on the vest.
  • An NIJ-resistant stab vest with more than one panel also mentions how many inserts are required to meet the required protection level. This warning must be there on the main stab-resistant insert panel.
  • There is also a declaration on the vest from the manufacturer stating that the stab vest has been tested to conform to NIJ standard 0115.00 for the protection class and level it is made for.

If all the above-mentioned criteria have been fulfilled, the stab vest is NIJ certified.

Is it Illegal to Wear a Stab-Proof Vest ?

Well, it is not possible to give an exact answer to whether it is legal to wear a stab vest or not. This completely depends on the state laws whether they allow anyone to buy and use stab vests. In most US states, it is legal to use these vests unless you have been convicted of a crime or intend to use the vest for any criminal offense. For example, in the USA, anyone (US citizen) above 18 with no criminal history can buy and wear a stab vest. On the other hand, there is an exception in New York, it is illegal to use a stab vest unless you are in a profession that needs to wear one.

Is it Legal to Wear a Stab-Proof Vest?

Again, this depends on US state laws. However, wearing a stab vest in public makes no sense until you are in a profession that needs one. Certain states prohibit using stab vests in public. You must have a purpose for wearing a stab vest. It could attract the attention of people, giving them a false sign that a threat may be nearby.

Are Stab Proof Vest Legal ?

Yes, stab-proof vests are legal but only for certain professions. Different laws are made in different countries regarding the purchase of these vests. Those guidelines must be fulfilled before owing one. Let us see the criteria for the use of these vests in some countries:

  • In Australia, posing stab vests without authorization is illegal, especially in some territories like South Australia, Queensland, New South Wales, and Victoria.
  • In some Canadian provinces, you need to have a license to own body armor.
  • In the European Union, body armor is only for military use.
  • In the United Kingdom, no such laws are there for the purchase and use of body armor.
  • In the United States, the use of stab vests and other body armor is legal except in certain states namely Connecticut, New York, Louisiana, and Kentucky.

So, it won’t be wrong to say that the legality of the use of body armor varies according to the region.

What is the Best Stab Proof Material?

Kevlar is the most commonly used material to manufacture stab vests. It is a synthetic fiber that possesses high tensile strength, heat resistance, and more importantly lightweight. Hence, it is the choice to manufacture stab-resistant vests. When compared to steel, Kevlar is 5 times stronger.

What Makes Kevlar Stab-Proof?

When Kevlar is spun, a fiber with excellent tensile strength is produced. Hence, it is nearly impossible to separate this tightly spun fiber. So, when a sharp or pointed object strikes, the fibers within catch it and absorb the energy generated. This makes Kevlar stabproof.

Do Stab Vests Expire?

The average life of stab vests is around 5 years if you take proper care of them. Material like Kevlar degrades after some time hence, it is advised not to use a stab vest after 5 years. However, it is always important to thoroughly check your stab-proof vest while you wear it for any signs of tear or damage. If there are already marks of stabbing or any other damage, it is advised not to use it.

Is Stab Proof Vest Also Bulletproof?

If you think that a stab vest can also offer protection against firearms, then you are widely inaccurate. Bulletproof vests are different from stab vests as they are made to protect against bullets, especially of high caliber. A bulletproof vest will not protect against sharp and pointed weapons like knives, spikes, and needles. While on the other hand, stab-resistant vests will offer no protection against bullets. So, you need to have different vests for both purposes and use one depending on the type of threat you have.

Why Consider Spike Protection in Stab-Proof Vests?

Spike protection is achieved by laminating Kevlar with hard plastic. This is because pointed objects can significantly penetrate Kevlar while increasing the chances of injury. However, choosing spike protection in a stab vest will offer complete protection against sharp-edged weapons like knives as well as pointed ones such as spikes. Thus, a combination of plastic coating and Kevlar keeps the vest lightweight while giving dual protection with the ability to absorb the energy of the impact.

So, do not take spike protection for granted while buying a stab vest as it is necessary.

Can a Knife Cut Through a Bulletproof Vest?

Bulletproof vests are designed to stop a bullet from injuring the user. The fibers in a bulletproof vest will trap the bullet, flatten it, and disperse the energy across the vest. However, a strike with a knife on a bulletproof vest will cut the fibers as they are not resistant to sharp-edged weapons. Whereas, when a spiked tool hits a bulletproof vest, it will penetrate through the gaps in the fiber. Hence, will offer no protection.

So, a bulletproof vest cannot protect knives and spikes.

Will a Stab-Resistant Vest Stop Slashing?

There is a difference between stab-resistant and slash-proof clothing. The former will only offer protection against stabbing, as the name implies. While on the other hand, slash-proof clothing protects against cutting strikes. So, there is no guarantee that a stab-proof vest will prevent slashing injuries.

What Effect Do Stab Proof Vest Have on Hand Gun Bullets?

When a bullet hits a stab-resistant vest, it will break the fibers and leave blunt trauma on the wearer’s body. Severe bullet injuries will also be there as stab vests cannot protect against firearms. Besides the trauma caused by the bullet, the force by which the vest will push against the body of the wearer after a bullet strike will also result in bruising.

What is the difference between a stab vest and a bulletproof vest?

As per the National Institute of Justice, body amours can be categorized under two heads: ballistic-resistant body amours and stab-resistant body amours. Each of these body amours serves a common objective, which is preventing something from penetrating the body of the wearer and also simultaneously reducing the blunt force trauma caused due to the high impact force so generated during action. To ensure complete body protection, it’s imperative to choose the body armor that best fits the user’s needs.

Stab Vest vs Bulletproof Vest

Many people use the terms stab vests and bulletproof vests interchangeably but, this is not correct. Both these body armors solve different purposes. Stab proof vests are designed to offer protection against pointed and sharp-edged weapons like knives, spikes, and needles. They are not effective against ballistic attacks, especially those of high caliber.

Now, when it comes to a bulletproof vest, it is designed to protect against bullets but not against sharp objects like knives. A knife attack on these vests will cut the protective fabric while putting the wearer at risk.

So, these are some of the commonly asked questions regarding stab vests. Hope you’ve got the answer to your question. Stay safe!
